一、The main technical parameters：

1、  Power requirements

voltage：380v±10%                          Power frequency：50Hz±1Hz

Power supply resistance：0.35Ω                Power capacity：40kVA

2、radiography conditions

Tube voltage： 40 ~ 150kV continuously adjustable

Tube current： 10 ~ 630 mA shift adjustment

Exposure time: 0.001 - 10 s

mAs range: 0.1 ~ 800 mAs

3、X-ray tube

Model: E7252X Small focus: 0.6 × 0.6mm2 High focus: 1.2 × 1.2 mm2 2800 r / min

Model: XD52-30.50 / 150 Small focus: 1.0 × 1.0mm2 Large focus: 2.0 × 2.0 mm2 2800 r / min (optional)

4、radiography bed

Bed size: 1200 × 700 × 750 (mm) (length × width × height)

Bed movement range: vertical ± 250mm  horizontal ± 100mm

Focus distance: 1200mm

5、X-ray tube assembly, column

Move up and down: 570 mm

Rotate around the center of the arm: ± 180º

6、Maximum size of film holder: 356mm × 432mm (14 "× 17")

7、Filter (fixed) Grid density: N103 Focal length: 1000mm

二、Features：

High power, high kV, suitable for large and medium-sized veterinary hospital use.

Designed for animal radiography, easy to operate.

Machine integrated design, small footprint.

South Korea aluminum-based fixed-line filter grid.

Big mA, short time, the image clearer.
